Locomotive Builder Sales Materials


A wide assortment of sales literature -- promotional brochures, catalogs and pamphlets -- are presented here in either a PDF or JPEG format. PDF-formatted documents will open full-size for viewing; however an Adobe Reader app will be needed to view them. To view JPEG-formatted documents, it will be necessary to utilize your browser zoom-in/out feature to achieve a preferred viewing size.

More documents will be added to this section at the end of each month, so please check back.

Graphic Link Document Description

Alco Diesel Switching Locomotives (1940)

37-page b&w catalog that describes in detail Alco's entire line of early diesel switching locomotives, includes drawings, photos and performance charts.

(R. Craig collection)

Alco FA Brochure (4/1946)

Four-page color brochure describing the features of Alco's new 1500-hp diesel freight locomotive

(R. Craig collection)

Alco FA Brochure (11/1946)

Mini brochure featuring a Howard Fogg painting of GM&O's new 4500-hp diesel freight locomotive set

(R. Craig collection)

Complete Line of New Diesel-Electric Locomotives (8/1946)

Sixteen-page multi-color brochure introducing Alco's new line of diesel-electric locomotives (Note how early sketches bore resemblance to Fairbanks Morse "Erie-builts," which GE also played a key role in designing. Relocation of grilled headlight to top of the Alco nose was a "master design stroke.")

(R. Craig collection)

Alco PA Brochure (10/1946)

Four-page color brochure introducing Alco's new streamlined 2000-hp diesel passenger locomotive

(R. Craig collection)

Alco PA Brochure (1947)

Pocket-size brochure featuring a Howard Fogg painting of Santa Fe's new 6000-hp diesel passenger locomotive set

(R. Craig collection)

BLW Centipede Brochure

Four-page, three-color sales brochure introducing the 3000-hp locomotive (1946)

(R. Craig collection)

EMD Locomtive Replacement Plan

Eight-page color sales brochure (5/1960) describing Electro-Motive Division's locomotive replacement plan

(R. Craig collection)

EMD_More productive...More profitable to meet today's challenges (1963)

Six-page color brochure delineating Electro-Motive Division's family of locomotives that replace all type of older power.

(Ted Grumbine collection)

Being Processed

EMD 645 Line Booklet

Eight-page color booklet (1966) describing Electro-Motive Division's entire line of locomotives driven by the new 645 engine.

(R. Craig collection)

EMD Motive Power Dependability Brochure

16-page booklet (ca. 1982) describing Electro-Motive Division's locomotive offerings

(Ted Grumbine collection)

EMD Major Component Evolution

Two-page color booklet (1987) describing Electro-Motive Division's changing technology from 1939 to present day.

(Ted Grumbine collection)

GE Power for Progress (9/1960)

Sixteen-page Multi-color sales brochure depicting General Electric's locomotive building history.

(Ted Grumbine collection)

GE Universal Series Brochure (6/63)

Eight-page color sales brochure promoting General Electric's entire U25B, U25C and U50 Universal series locomotives.

(R. Craig collection)

GE U25B Specification Booklet (6/63)

Twelve-page black & white booklet outlining the engine specifications and dimensions of the U25B

(R. Craig collection)

GE U30 Brochure (1965)

Four-page color sales brochure introducing General Electric's new U30B, U30C and U30CG diesel locomotives.

(R. Craig collection)

GE U33 Brochure (1965)

Four-page color sales brochure introducing General Electric's new U33 Series diesel locomotives.

(R. Craig collection)

GE Dash-8 Brochure (8/1987)

Sixteen-page full-color sales brochure introducing General Electric's entire line of "Dash 8" locomotives.

(Ted Grumbine collection)

Blank
